Lab Design 8 foot walk in fume hood
Manufacturer: Lab Design
Model: WI-96 Walk In
Condition: New. Ships from manufacturer.
Estimated lead time: Typically 8 weeks from receipt of order and payment. Contact us for availability.
Please specify which accessories are required when requesting a quote.
Features:
- By-pass airflow design with variable air volume compatibility.
- Air Foil with aerodynamic airflow openings.
- Rear Downflow Dual Baffle System.
- Chemical-resistant, fiberglass-reinforced, composite panel liner and baffles with flame spread index less than 25 per ASTM E84. Baffles are removable for cleaning.
- Tempered safety glass vertical-rising sash with cable pulley.
- Removable front and side panels, and front and interior service access panels for access to plumbing and electrical wiring.
- Pre-wired LED lighting with vapor-proof design and ADA-compliant light and blower switches. Lighting is rated for 50,000 hours.
Includes:
- 8 foot wide walk in fume hood with vertical sash
- (2) duplex outlets
- (2) gas fixtures
- (1) cold water fixture with gooseneck faucet
- (1) side mounted cupsink
- Pallet and packaging
Specifications
- Width: 8 foot
- Region: U.S. and Canada
- Blower Requirements: Remote blower required. Sold separately
- Conformance: ANSI Z9.5, ASHRAE 110, ASTM E84, CAN/CSA C22.2, NFPA 45, SEFA 1, UL
- Electrical Duplexes: 1
- Lighting: LED
- Service Fixtures: 3
- Style: Walk In
- Enclosure Height: 96"
- Estimated Shipping Weight: 1270.0 lbs
- Dimensions: 96.0" w x 37.7" d x 96" high
- Electrical: 100-115V, 50/60Hz, 10A
Accessories
- Remote roof mounted exhaust blower
- Gas Fixture kit (Your choice of nitrogen, gas, compressed air, argon gas, and vacuum). Specify type and quantity upon order.
- Cold water fixture kit with wall mounted cupsink
- Distillation Rack
